Manufacturing Standards
TIA/EIA568-C-2, ISOIIEC11801, EN50173, YDIT1019
describe
It is suitable for various network cabling, various transmission media and Internet of Things communications, etc., and can meet the data transmission range of the maximum bandwidth of 10Base-T, 1000Base-TX, and 622M ATM. It has large digital transmission bandwidth margin space and strong anti-interference ability of shielded cables. .
feature
1. Made of high-purity oxygen-free copper, non-directional, high-purity and anti-corrosion, high-speed and stable signal transmission.
2. The product has passed UL444 certification and is of high quality.
name | Product Description |
UTPCAT5e | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + sheath (polyvinyl chloride) |
FTPCAT5e | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + polyester film + drain wire + aluminum foil + sheath (polyvinyl chloride) |
SFTPCAT5e | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + polyester film + drain wire + aluminum foil + braid (bare copper) + sheath (polyvinyl chloride) |
UTPCAT6 | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + skeleton + sheath (polyvinyl chloride) |
FTPCAT6 | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + skeleton + polyester film + drainage wire + aluminum foil + sheath (polyvinyl chloride) |
SFTPCAT6 | Conductor (oxygen-free copper) + insulation (high-density polyethylene) + skeleton + polyester film + drain wire + aluminum foil + braid (bare copper) + sheath (polyvinyl chloride) |
